Board Thickness :

0.094"" (2.39mm)

Contact Finish :

Electro-Tin

Contact Finish Thickness :

300.0µin (7.62µm)

Contact Material :

Brass

Diameter - Turret Head :

0.040"" (1.02mm)

Flange Diameter :

0.125"" (3.18mm)

Insulation :

Non-Insulated

Length - Above Board :

0.187"" (4.75mm)

Length - Below Flange :

0.140"" (3.56mm)

Length - Overall :

0.327"" (8.31mm)

Mounting Hole Diameter :

0.082"" (2.08mm)

Mounting Type :

Through Hole

Number of Turrets :

Single

Part Status :

Active

Staking Side ID :

0.055"" (1.40mm)

Staking Side OD :

0.078"" (1.98mm)

Terminal Type :

Single End

Termination :

Swage
