Board Thickness :

0.031"" (0.79mm)

Contact Finish :

Electro-Tin

Contact Finish Thickness :

300.0µin (7.62µm)

Contact Material :

Brass

Flange Diameter :

0.070"" (1.77mm)

Insulation :

Non-Insulated

Length - Above Flange :

0.040"" (1.02mm)

Length - Below Flange :

0.320"" (8.13mm)

Length - Overall :

0.371"" (9.42mm)

Mounting Hole Diameter :

0.042"" ~ 0.044"" (1.07mm ~ 1.12mm)

Mounting Type :

Through Hole

Part Status :

Active

Pin Size - Above Flange :

0.040"" (1.02mm) Dia

Pin Size - Below Flange :

0.040"" (1.02mm) Dia

Terminal Style :

Single End

Terminal Type :

PC Pin

Termination :

Swage
